Schweitzer Engineering Laboratories SEL-734 - Table A.2 Instruction Manual Revision History

A.7
Date Code 20090730 Instruction Manual SEL-734 Meter
Firmware and Manual Versions
Instruction Manual
Instruction Manual
The date code at the bottom of each page of this manual reflects the creation or revision date.
Table A.2 lists the instruction manual release dates and a description of modifications. The most recent instruction
manual revisions are listed at the top.
Form 5 Meter
SEL-734-R505-V0-Z002001-D20040130
Form 9 Meter
SEL-734-R105-V0-Z002001-D20040130
➤ Enable VB_RMS, VC_RMS on display points.
➤ Enable Date, Time, and Date/Time on display points.
➤ Enable DST support for Southern Hemisphere.
➤ Improved metering accuracy in reverse power flow conditions.
➤ Enable single-phase calibration testing of Form 5 meters.
20040130
Form 5 Meter
SEL-734-R504-V0-Z001001-D20031101
Form 9 Meter
SEL-734-R104-V0-Z001001-D20031101
➤ Resolve DNP and Test Mode conflict.
➤ Release SELBOOT R101, which allows firmware uploads on Port 3.
➤ Set PMDOK bit when phasor data is valid.
20031103
Form 5 Meter
SEL-734-R503-V0-Z001001-D20030825
Form 9 Meter
SEL-734-R103-V0-Z001001-D20030825
➤ Limits password string length to eight characters. 20030825
Form 5 Meter
SEL-734-R502-V0-Z001001-D20030730
Form 9 Meter
SEL-734-R102-V0-Z001001-D20030730
➤ Initial version. 20030730
Table A.2 Instruction Manual Revision History (Sheet 1 of 2)
Revision
Date
Summary of Revisions
20090730
Appendix A
➤ Updated for firmware version R132/R532.
20090717
Section 1
➤ Removed ordering information from SEL-734 Meter Forms and Models.
➤ Updated Table 1.2: SEL-734 Feature Availability.
➤ Updated Harmonic Accuracy and Flicker information in Specifications.
Section 2
➤ Added Figure 2.3: SEL-734 Easily Extractable Meter (EXM) Mounting Dimensions.
Section 4
➤ Updated Table 4.18: Meter Configuration Record.
Section 8
➤ Updated Table 8.3: Counter Inputs and Outputs.
Section 9
➤ Updated text under Rollover.
Section 10
➤ Updated Flicker Evaluation information in MET FL (Flicker Metering).
Section 12
➤ Updated TEST mode list in TEST Mode Considerations.
Appendix A
➤ Updated for firmware version R131/R531.
Table A.1 Firmware Revision History (Sheet 7 of 7)
Firmware Identification (FID) Number Summary of Revisions
Manual
Date Code
