SICK microScan3 User Manual

•
S
afety Designer, Overview dialog (only with connected device)
•
Safety Designer, report
Table 29: Functional scope of the microScan3 Core – PROFINET (RJ45) (devices with a max.
protective field range of 4.0 m and devices with max. protective field range of 5.5 m)
Version number Amendments and new functions
1.0.0
•
F
irst released version
1.1.0
•
Option to adjust the settings for multiple sampling after switch‐
ing between monitoring cases
•
Data output via UDP and TCP/IP (measurement data, field
interruption, application data, process information)
1.2.0
•
Time synchronization via SNTP
1.3.0
•
P
ROFINET process image (non-safety-related)
1.4.0
•
New rights management using user group Administrator (now 4
user groups)
•
Additional third option for resetting to factory settings
•
Modified process for resetting the password
•
Deviating multiple sampling after object detection can be con‐
figured
•
Interfaces and selected functions can be activated or deacti‐
vated
•
New Always ON (NON-safe) function in monitoring case tables
Table 30: Functional scope of the microScan3 Core – PROFINET (RJ45) (devices with a max.
protective field range of 9.0 m)
Version number Amendments and new functions
1.0.0
•
F
irst released version, including the following functions:
°
Option to adjust the settings for multiple sampling after
switching between monitoring cases
°
Data output via UDP and TCP/IP (measurement data, object
detection, application data, process information)
1.1.0
•
T
ime synchronization via SNTP
1.2.0
•
PROFINET process image (non-safety-related)
1.3.0
•
New rights management using user group Administrator (now 4
user groups)
•
Additional third option for resetting to factory settings
•
Modified process for resetting the password
•
Deviating multiple sampling after object detection can be con‐
figured
•
Interfaces and selected functions can be activated or deacti‐
vated
•
New Always ON (NON-safe) function in monitoring case tables
Table 31: Functional scope of the microScan3 Core – PROFINET (SCRJ)
Version number Amendments and new functions
1.0.0
•
F
irst released version, including the following functions:
°
Option to adjust the settings for multiple sampling after
switching between monitoring cases
°
Data output via UDP and TCP/IP (measurement data, field
interruption, application data, process information)
°
Time synchronization via SNTP
1.1.0
•
PROFINET process image (non-safety-related)
13 TECHNICAL DATA
162
O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET 8021219/1ELL/2022-01-21 | SICK
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
