microScan3 Core – PROFINET microScan3 Pro – PROFINET
Standards
•
IE
C 60068-2-27
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC 60721-3-5)
•
3M4 (IEC TR 60721-4-3)
Single shock 50 m/s², 11 ms
Continuous shock
•
100 m/s², 16 ms
•
150 m/s², 6 ms
EMC In accordance with IEC 61496-1, IEC 61000-6-2, and
IE
C 61000-6-4
1)
The specified enclosure rating is only valid if the safety laser scanner is closed, the system plug and the
cover plate are mounted, and all of the M12, RJ45 and SCRJ plug connectors of the safety laser scanner
have been closed using a cable plug connector suitable for the enclosure rating or using a protective cap.
2)
For ambient light sources directly in the scan plane in accordance with IEC 61496-3: ≤ 3 klx.
3)
IEC 61496-1, no. 4.3.1 and no. 5.4.2, IEC 61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
influence on normal operation.
4)
In direct mounting.
Miscellaneous data
T
able 44: Miscellaneous data
microScan3 Core – PROFINET microScan3 Pro – PROFINET
Wavelength 845 nm
Detectable remission 1.8% … several 1000% 1.8% to several 1,000%
Maximum uniform contami‐
na
tion of the optics cover
without reducing the detec‐
tion capability
1)
30%
Area where detection capabil‐
it
y is restricted
≤ 50 mm
2)
Light spot size
3)
Devices with a max. protective field range of 4.0 m
At front screen 18 mm × 4 mm
At 4.0 m distance 5 mm × 11 mm
At 5.5 m distance 2 mm × 18 mm
At 9.0 m distance 11 mm × 27 mm
Devices with max. protective field range 5.5 m
At front screen 18 mm × 4 mm
At 4.0 m distance 5 mm × 11 mm
At 5.5 m distance 2 mm × 18 mm
At 9.0 m distance 11 mm × 27 mm
Devices with max. protective field range 9.0 m
At front screen 18 mm × 4 mm
At 4.0 m distance 8 mm × 14 mm
At 5.5 m distance 4 mm × 19 mm
At 9.0 m distance 2 mm × 30 mm
Divergence of collimated
be
am
0.17°
TECHNICAL DATA 13
8021219/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET
171
Subject to change without notice
