Mechanical data
T
able 42: Mechanical data
microScan3 Core – PROFINET microScan3 Pro – PROFINET
Dimensions (without system plug, W × H × D)
Devices with RJ45 connec‐
t
ion
112 mm × 163.1 mm × 111.1 mm
Devices with SCRJ connec‐
t
ion
112 mm × 163.1 mm × 111.1 mm
Devices with M12 connec‐
tion
112 mm × 150.8 mm × 111.1 mm
Weight (including system plug)
Devices with RJ45 connec‐
t
ion
1.65 kg
Devices with SCRJ connec‐
tion
1.65 kg
Devices with M12 connec‐
tion
1.45 kg
Housing material Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Optics cover surface Outside with scratch-resistant coating
Ambient data
T
able 43: Ambient data
microScan3 Core – PROFINET microScan3 Pro – PROFINET
Enclosure rating
1)
IP65 (IEC 60529) IP 65 (IEC 60529)
Ambient light immunity ≤ 40 klx
2)
Ambient operating tempera‐
t
ure
–10 °C … 50 °C
Storage temperature -25 °C … 70 °C –25 °C … 70 °C
Air humidity ≤ 95%, non-condensing
3)
Height above sea level during
oper
ation
≤ 2300 m
Vibration resistance
4)
Standards
•
IE
C 60068-2-6
•
IEC 60068-2-64
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC 60721-3-5)
•
3M4 (IEC TR 60721-4-3)
Sinusoidal vibrations
•
50 m/s², 0.35 mm, 10 Hz … 150 Hz
•
5 m/s², 1.5 mm, 5 Hz … 200 Hz
•
10 m/s², 3.5 mm, 5 Hz … 150 Hz
Noise vibrations
•
0.5 m²/s³, 5 Hz … 200 Hz
•
0.1 m²/s³, 200 Hz … 500 Hz
Shock resistance
4)
13 TECHNICAL DATA
170
O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET 8021219/1ELL/2022-01-21 | SICK
Subject to change without notice
