The logical variables can be linked in turn to the outputs (Q) in the Switching outputs
area.
Example:
Q1 = LogVar1
The output Q1 switches when the total number of beams made is greater than or
equal to 30 or when the number of consecutive beams blocked equals 5.
NOTE
If outputs have already been configured using the operating elements available in the
Easy user level, these settings will be automatically transferred to the Function program‐
ming view.
