SICK MLG-2 Pro - Graph, Distances When Light Is in the same Direction

MLG-2 with 2 m sensing range
0 mm
200 mm
400 mm
600 mm
800 mm
0.0 m 2.0 m 4.0 m 6.0 m 8.0 m
Y
XOperating range
Minimum distance
MLG-2 with 5 m and 8.5 m sensing range
Figure 28: Graph, distances when light is in the same direction
