3.2.2 Combinations of MLG-2 Pro inputs and outputs
Position 12 Inputs and outputs, data interface Connection type
B 2 × switching output (Q) and
2 × analog output (QA)
or
1 × input (IN) and
1 × switching output (Q) and
2 × analog output (QA)
M12/8-pin, A-coded
I 2 × switching output (Q) and
1 × RS-485 interface
or
1 × input (IN) and
1 × switching output (Q) and
1 × RS-485 interface
M12/8-pin, A-coded
R 4 × switching output (Q)
or
2 × input (IN) and
2 × switching output (Q)
M12/8-pin, A-coded
Table 5: Possible combinations of MLG-2 Pro inputs and outputs
3.2.3 Optical properties
Position
14 and 15
Sensing range Minimum detectable object length
00 Special Special
32 2 m 2.5 mm
05 5 m 5 mm
08 8.5 m 5 mm
Table 6: Sensing range and minimum detectable object length
3.2.4 MLG-2 Pro preconfigurations
Position
16, 17
QA1 QA2 Q1/C Q2/IN1 Teach-in
01 NBB LBB Object detection Teach-in Standard operating
mode
02 NBB LBB Object detection Object detection
(inverted)
Standard operating
mode
03 NBB LBB Object detection Object detection
(inverted)
Standard & cross
beam operating
mode
04 NBB FBB Object detection Teach-in Standard operating
mode
05 NBB FBB Object detection Object detection
(inverted)
Standard operating
mode
06 NBB FBB Object detection Object detection
(inverted)
Standard & cross
beam operating
mode
Table 7: Preconfiguration of MLG-2 Pro with I/O combination B (see table 5, page 13)
PRODUCT DESCRIPTION 3
8017460.ZIK1/2017-02-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 Pro
13
Subject to change without notice
