7.14.1 Beam functions
Name Function (English) Function (German) Description
NBB Number of Beams
Blocked
Anzahl unterbroch‐
ener Strahlen
Total number of beams blocked (e.g.,
for object detection)
NBM Number of Beams
Made
Anzahl freier Strah‐
len
Total number of beams made (e.g.,
for hole detection)
NCBB Number of Consecu‐
tive Beams Blocked
Anzahl zusammen‐
hängender unter‐
brochener Strahlen
If there are multiple objects in the
detection area, the greatest number
of consecutive beams blocked is dis‐
played.
NCBM Number of Consecu‐
tive Beams Made
Anzahl zusammen‐
hängender freier
Strahlen
If there are multiple gaps in the
detection area, the greatest number
of consecutive beams made is dis‐
played.
LBB Last Beam Blocked Letzter unterbroch‐
ener Strahl
Beam number of the last beam
blocked (e.g., for object height meas‐
urement)
LBM Last Beam Made Letzter freier Strahl Beam number of the last beam
made
FBB First Beam Blocked Erster unterbroch‐
ener Strahl
Beam number of the first beam
blocked (e.g., for height classification
of a hanging object)
FBM First Beam Made Erster freier Strahl Beam number of the first beam
made
ODI Outside
Dimension
Außenmaß Total number of beams between the
first and last beams blocked (e.g., for
measuring the outside dimension)
IDI Inside
Dimension
Innenmaß Total number of beams made
between the first and last beams
blocked (e.g., for measuring the
inside dimension)
CBB Central Beam
Blocked
Zentraler unter‐
brochener Strahl
Beam number of the central beam
blocked (e.g., for measuring an
object position)
CBM Central Beam Made Zentraler freier
Strahl
Beam number of the central beam
made (e.g., for measuring a hole
position)
BNB Beam Number
Blocked
Strahlnummer x
unterbrochen
True when a predefined beam is
blocked
BNM Beam Number Made Strahlnummer x frei True when a predefined beam is
made
ALARM Q1 – – Configuration same as with SOPAS
ET
QoR Quality of Run Process quality 0 … 100 percent
QoT Quality of Teach Teach-in quality 0 or 100 in percent
0 = teach-in was unsuccessful
100 = teach-in was successful
RLC1 … 16 Run-length code – Outputs the value of the relevant
change
NBB Zone X
(X = 1, 2, 3
or 4)
Number of Beams
Blocked Zone X
Number of Beams
Blocked Zone X
Total number of beams blocked (e.g.,
for object detection) in the indicated
zone
Table 33: Beam functions for preliminary evaluation
