SICK MLG-2 Pro User Manual

13 Technical data
13.1 Data sheet
General data
Protection class III (EN 61140)
Enclosure rating IP 65 and IP 67 (EN 60529)
1
Class according to UL 60947 Class 2
Ambient operating temperature (UL/CSA:
surrounding air temperature)
–30 … +55 °C
Storage temperature –40 … +70 °C
Vibration resistance Sine-wave vibration 10-150 Hz 5 g
Shock resistance Continuous shocks 10 g, 16 ms, 1000 shocks
Single shocks 15 g, 11 ms, 3 per axis
Electromagnetic compatibility According to EN 61000-6-2 Interference immunity
for industrial environments and EN 61000-6-4
Emission standard for industrial environments
MTTF 15 years
Dimensions see "Dimensional drawings", page 126
Weight Sender + receiver approx. 2 kg/m + 0.1 kg
Materials
•
Housing
•
Front screen
•
Aluminum, anodized
•
PMMA
Firmware version see "Type labels of the MLG-2 Pro", page 11
Table 43: MLG-2 data sheet - general data
1
Do not use light grids outdoors unless protected (condensation will form).
Electrical specifications (for 24 VDC and 25 °C ambient temperature)
Supply voltage V
S
24 VDC ± 20%
Residual ripple (within V
S
) < 10%
Current consumption of sender
•
Typical
•
Maximum
•
With 3x high-speed scan
•
40 mA + (0.05 mA × number of beams)
•
< 55 mA + (0.05 mA × number of beams)
•
< 110 mA + (0.05 mA × number of beams)
Current consumption of receiver
•
Typical
•
MLG-2 Pro maximum
•
In sunlight-resistant mode where a
beam of 150 klx is sent to all
receiver optics
•
80 mA + (0.25 mA × number of beams)
•
< 120 mA + (0.2 mA × number of beams)
•
< 120 mA + (0.5 mA × number of beams)
Table 44: MLG-2 data sheet - electrical specifications
TECHNICAL DATA 13
8017460.ZIK1/2017-02-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 Pro
119
Subject to change without notice
