Table 10-26 PM240P-2, IP20, frame sizes E, 3 AC 500 V … 690 V
Article number without filter
Article number with filter
6SL3210-1RH25-2UL0
6SL3210-1RH25-2AL0
6SL3210-1RH26-2UL0
6SL3210-1RH26-2AL0
LO base load power 45 kW 55 kW
LO base load input current 50 A 59 A
LO base load output current 52 A 62 A
HO base load power 37 kW 45 kW
HO base load input current 44 A 54 A
HO base load output current 42 A 52 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA1820-0 / 80 A
80 A
3NE1820-0 / 80 A
80 A
Power loss without filter 1.00 kW 1.21 kW
Power loss with filter 1.00 kW 1.22 kW
Required cooling air flow 83 l/s 83 l/s
Weight without filter 26 kg 26 kg
Weight with filter 28 kg 28 kg
Table 10-27 PM240-2, IP20, frame size F, 3 AC 500 V … 690 V
Article number without filter
Article number with filter
6SL3210-1RH28-0UL0
6SL3210-1RH28-0AL0
6SL3210-1RH31-0UL0
6SL3210-1RH31-0AL0
6SL3210-1RH31-2UL0
6SL3210-1RH31-2AL0
LO base load power 75 kW 90 kW 110 kW
LO base load input current 78 A 97 A 111 A
LO base load output current 80 A 100 A 115 A
HO base load power 55 kW 75 kW 90 kW
HO base load input current 66 A 85 A 106 A
HO base load output current 62 A 80 A 100 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1021-0 / 100 A
110 A
3NE1022-0 / 125 A
150 A
3NE1224-0 / 160 A
150 A
Power loss without filter 1.34 kW 1.71 kW 2 kW
Power loss with filter 1.35 kW 1.72 kW 2.02 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight without filter 60 kg 60 kg 60 kg
Weight with filter 64 kg 64 kg 64 kg
Table 10-28 PM240-2, IP20, frame size F, 3 AC 500 V … 690 V
Article number without filter
Article number with filter
6SL3210-1RH31-4UL0
6SL3210-1RH31-4AL0
LO base load power 132 kW
LO base load input current 137 A
LO base load output current 142 A
HO base load power 110 kW
Technical data
10.4 Technical Data, PM240P-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 461
