Power Module Power Output reactor
FSF 6SL3223-0DE35‑5 . A0 55 kW 6SE6400-3TC14-5FD0
6SL3223-0DE37‑5 . A0 75 kW 6SE6400-3TC15-4FD0
6SL3223-0DE38‑8 . A0 90 kW 6SE6400-3TC14-5FD0
Output reactors for PM230 Power Modules (IP20)
Power Module Power Output reactor
FSA 6SL3210-1NE11-3 . G1
6SL3210-1NE11-7 . G1
6SL3210-1NE12-2 . G1
6SL3210-1NE13-1 . G1
6SL3210-1NE14-1 . G1
6SL3210-1NE15-8 . G1
0.37 kW … 2.2 kW 6SL3202-0AE16-1CA0
6SL3210-1NE17‑7 . G1 3.0 kW 6SL3202-0AE18-8CA0
FSB 6SL3210-1NE21-0 . G1
6SL3210-1NE21-3 . G1
6SL3210-1NE21-8 . G1
4.0 kW … 7.5 kW 6SL3202-0AE21-8CA0
FSC 6SL3210-1NE22-6 . G1
6SL3210-1NE23-2 . G1
6SL3210-1NE23-8 . G1
11.0 kW … 18.5 kW 6SL3202-0AE23-8CA0
FSD 6SL3210-1NE24‑5 . L0 22 kW 6SE6400-3TC03-8DD0
6SL3210-1NE26‑0 . L0 30 kW 6SE6400-3TC05-4DD0
FSE 6SL3210-1NE27‑5 . L0 37 kW 6SE6400-3TC08-0ED0
6SL3210-1NE28‑8 . L0 45 kW 6SE6400-3TC07-5ED0
FSF 6SL3210-1NE31‑1 . L0 55 kW 6SE6400-3TC14-5FD0
6SL3210-1NE31‑5 . L0 75 kW 6SE6400-3TC15-4FD0
Output reactors for PM230 push-through Power Modules
Power Module Power Output reactor
FSA 6SL3211-1NE17-7 . G1 3.0 kW 6SL3202-0AE18-8CA0
FSB 6SL3211-1NE21-8 . G1 7.5 kW 6SL3202-0AE21-8CA0
FSC 6SL3211-1NE23-8 . G1 18.5 kW 6SL3202-0AE23-8CA0
Output reactors for PM240-2 Power Modules, 380 V … 480 V
Power Module Power Output reactor
FSA 6SL3210-1PE11-8 . L1,
6SL3210-1PE12-3 . L1,
6SL3210-1PE13-2 . L1,
6SL3210-1PE14-3 . L1,
6SL3210-1PE16-1 . L1
0.55 kW … 2.2 kW 6SL3202-0AE16-1CA0
6SL321 . -1PE18-0UL1 3 kW 6SL3202-0AE18-8CA0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 47
