Power Module Power Output reactor
FSB 6SL3210-1PE21-1 . L0,
6SL3210-1PE21-4 . L0,
6SL321 . -1PE21-8 . L0
4 kW … 7.5 kW 6SL3202-0AE21-8CA0
FSC 6SL3210-1PE22-7 . L0,
6SL321 . -1PE23-3 . L0
11 kW … 15 kW 6SL3202-0AE23-8CA0
FSD 6SL3210-1PE23-8 . L0
6SL3210-1PE24-5 . L0
6SL3210-1PE26-0 . L0
6SL3210-1PE27-5 . L0
18.5 kW … 37 kW 6SE6400-3TC07-5ED0
FSE 6SL3210-1PE28-8 . L0,
6SL3210-1PE31-1 . L0,
6SL3210-1PE31-5 . L0,
6SL3210-1PE31-8 . L0
45 kW … 90 kW 6SE6400-3TC14-5FD0
FSF 6SL3210-1PE32-1 . L0 110 kW 6SL3000-2BE32-1AA0
6SL3210-1PE32-5 . L0 132 kW 6SL3000-2BE32-6AA0
Output reactors for PM240-2 Power Modules, 500 V … 690 V
Power Module Power Output reactor
FSF 6SL3210-1PH28-0 . L0,
6SL3210-1PH31-0 . L0
75 kW … 90 kW 6SL3000-2AH31-0AA0
6SL3210-1PH31-2 . L0,
6SL3210-1PH31-4 . L0
110 kW … 132 kW 6SL3000-2AH31-5AA0
Output reactors for PM240-2 Power Modules, 200 V … 240 V
Power Module Power Output reactor
FSA 6SL3210-1PB13-0 . L0,
6SL321 . -1PB13-8 . L0
0.55 kW … 0.75 kW 6SL3202-0AE16-1CA0
FSB 6SL3210-1PB15-5 . L0 1.1 kW
6SL3210-1PB17-4 . L0 1.5 kW 6SL3202-0AE18-8CA0
FSB 6SL321 . -1PB21-0 . L0 2.2 kW 6SL3202-0AE21-8CA0
FSC 6SL3210-1PB21-4 . L0,
6SL321 . -1PB21-8 . L0
3 kW … 4 kW
6SL321 . -1PC22-2 . L0,
6SL3210-1PC22-8 . L0
5.5 kw … 7.5 kW 6SL3202-0AE23-8CA0
FSD 6SL3210-1PC24-2UL0,
6SL3210-1PC25-4UL0,
6SL3210-1PC26-8UL0
11 kW … 18.5 kW 6SE6400-3TC07-5ED0
FSE 6SL3210-1PC28-0UL0,
6SL3210-1PC31-1UL0
22 kW … 55 kW 6SE6400-3TC14-5FD0
FSF 6SL3210-1PC31-3UL0,
6SL3210-1PC31-6UL0,
6SL3210-1PC31-8UL0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
48 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
