Output reactors for PM330 Power Modules, 380 V … 480 V
Power Module Power Output reactor
GX 6SL3310-1PE33‑0AA0 160 kW 6SL3000-2BE33-2AA0
6SL3310-1PE33‑7AA0 200 kW 6SL3000-2BE33-8AA0
6SL3310-1PE34-6AA0 250 kW 6SL3000-2BE35-0AA0
HX 6SL3310-1PE35-8AA0 315 kW 6SL3000-2AE36-1AA0
6SL3310-1PE36-6AA0 355 kW 6SL3000-2AE38-4AA0
6SL3310-1PE37-4AA0 400 kW
JX 6SL3310-1PE38-4AA0,
6SL3310-1PE38-8AA0
450 kW … 500 kW 6SL3000-2AE41-0AA0
6SL3310-1PE41-0AA0 560 kW 6SL3000-2AE41-4AA0
Output reactors for PM330 Power Modules, 500 V … 690 V
Power Module Power Output reactors
JX 6SL3310-1PG35-8AA0,
6SL3310-1PG36-5AA0,
6SL3310-1PG37-2AA0
500 kW … 630 kW 6SL3000-2AE41-0AA0
Output reactors for PM240P-2 Power Modules, 380 V … 480 V
Power Module Power Output reactor
FSD 6SL3210-1RE24-5 . L0 22 kW 6SE6400-3TC03-8DD0
6SL3210-1RE26-0 . L0 30 kW 6SE6400-3TC07-5ED0
6SL3210-1RE27-5 . L0 37 kW
FSE 6SL3210-1RE28-8 . L0 45 kW
6SL3210-1RE31-1 . L0 55 KW 6SE6400-3TC14-5FD0
FSF 6SL3210-1RE31-5 . L0 75 kW
6SL3210-1RE31-8 . L0 90 kW
6SL3210-1RE32-1 . L0 110 kW 6SL3000-2BE32-1AA0
6SL3210-1RE32-5 . L0 132 kW 6SL3000-2BE32-6AA0
Output reactors for PM250 Power Module
Power Module Power Output reactor
FSC 6SL3225-0BE25‑5 . A0,
6SL3225-0BE27‑5 . A0,
6SL3225-0BE31‑1 . A0
7.5 kW … 15.0 kW 6SL3202-0AJ23-2CA0
FSD 6SL3225-0BE31-5 . A0 18.5 kW 6SE6400-3TC05-4DD0
6SL3225-0BE31-8 . A0 22 kW 6SE6400-3TC03-8DD0
6SL3225-0BE32-2 . A0 30 kW 6SE6400-3TC05-4DD0
FSE 6SL3225-0BE33-0 . A0 37 kW 6SE6400-3TC08-0ED0
6SL3225-0BE33-7 . A0 45 kW 6SE6400-3TC07-5ED0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 49
