Table 10-58 PM240-2, IP20, Frame Size D, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1PE27-5UL0
6SL3210-1PE27-5AL0
LO base load power 37 kW
LO base load input current 70 A
LO base load output current 75 A
HO base load power 30 kW
HO base load input current 62 A
HO base load output current 60 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3830 (100 A)
100 A
Power loss without filter 1.09 kW
Power loss with filter 1.10 kW
Required cooling air flow 55 l/s
Weight without filter 17 kg
Weight with filter 18.5 kg
Table 10-59 PM240-2, PT, frame size D, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3211-1PE27-5UL0
6SL3211-1PE27-5AL0
LO base load power 37 kW
LO base load input current 70 A
LO base load output current 75 A
HO base load power 30 kW
HO base load input current 62 A
HO base load output current 60 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3830 (100 A)
100 A
Power loss without filter 1.09 kW
1)
Power loss with filter 1.10 kW
1)
Required cooling air flow 55 l/s
Weight without filter 20 kg
Weight with filter 21.5 kg
1)
Approx. 1 kW through the heatsink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
492 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
