Table 10-60 PM240-2, IP20, Frame Size E, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1PE28-8UL0
6SL3210-1PE28-8AL0
6SL3210-1PE31-1UL0
6SL3210-1PE31-1AL0
LO base load power 45 kW 55 kW
LO base load input current 86 A 104 A
LO base load output current 90 A 110 A
HO base load power 37 kW 45 kW
HO base load input current 78 A 94 A
HO base load output current 75 A 90 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3832 (125 A)
125 A
3NA3836 (160 A)
150 A
Power loss without filter 1.29 kW 1.65 kW
Power loss with filter 1.30 kW 1.67 kW
Required cooling air flow 83 l/s 83 l/s
Weight without filter 26 kg 26 kg
Weight with filter 28 kg 28 kg
Table 10-61 PM240-2, PT, frame size E, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3211-1PE31-1UL0
6SL3211-1PE31-1AL0
LO base load power 55 kW
LO base load input current 104 A
LO base load output current 110 A
HO base load power 45 kW
HO base load input current 94 A
HO base load output current 90 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3836 (160 A)
150 A
Power loss without filter 1.65 kW
1)
Power loss with filter 1.67 kW
1)
Required cooling air flow 83 l/s
Weight without filter 30.5 kg
Weight with filter 32 kg
1)
Approx. 1.4 kW through the heatsink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 493
