service.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
12-37
Nur für den internen Gebrauch Service
Guided Maintenance
12.4 Guided Maintenance
12.4.1 Assessing Displays on the HG 1500 Front Panel
The HG 1500 board has a front panel that displays the status of the V24 and the two LAN in-
terfaces, the assignment of the individual resources (H323, D.38, and PPP) as well as the as-
signment of the DSP channels.
For more information, see the HG 1500 administrator documentation.
12.4.2 Recording HiPath 3000 Board Status
12.4.2.1 Central Control Boards
Run LED
A RUN LED that displays the system’s operating capacity is located on the central control
board.
Table 12-2 RUN LED - LED Status Meaning
RUN LED Meaning
Off No power
On Reset switch pressed briefly
Off Reset switch held down for more than 5 seconds (LED is extinguished
to acknowledge that a reload has begun)
On System boot
Off
for 0.1 s
Load operation: APS in SDRAM, loadware, and card data
Flashing
0.5 s on/0.5 s off
Normal operating state (zero load)
1
1 The flashing rhythm depends on the load. The higher the system load the slower the flashing rhythm.
Flashing
0.1 s on/0.1 s off
MMC removed or defective
