inst_h3.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
4-27
Nur für den internen Gebrauch Installing HiPath 3000
Installing HiPath 3800
4.1.4.4 Grounding the System
Ground the system as described.
Grounding: Inspection and Implementation
Implementation guidelines in accordance with IEC 60364 and IEC 60950-1 must be adhered
to during installation.
Preliminary Inspection of the 19-Inch Cabinet:
Is the 19-inch cabinet grounded
by a separate ground conduc-
tor (green/yellow)?
The 19-inch cabinet must be grounded by a sepa-
rate ground conductor (green/yellow).
Danger
If your personnel are not qualified to work on the
low-voltage network (230 Vac), you must hire a li-
censed electrician to install the ground. The
Section 1.6.1, “Connection to the Power Circuit” is
to be adhered to.
Does the 19-inch cabinet have
a potential equalization bus
at which the HiPath 3800 can be
grounded as shown in Figure 4-
13 ?
A potential equalization bus must be installed in
the 19-inch cabinet and connected to the ground
conductor.
Danger
If your personnel are not qualified to work on the
low-voltage network (230 Vac), you must hire a li-
censed electrician to install the ground. The
Section 1.6.1, “Connection to the Power Circuit” is
to be adhered to.
If you answer “Yes” to both questions, the system (system cabinets, patch panels) may be
grounded as described below.
NO
YES
NO
YES
To Next Page
