3.4.17 V.24 Adapter

The V.24 adapter is required as an adapter between the 25-pin connector on the cable

(C39195-Z7267-C13) and a 9-pin jack for connection to the V.24 interface on all HiPath 3000

V1.2 (or later) systems.

V.24 adapter assignment

Table 3-188 V.24 Adapter Assignment (C39334-Z7080-C2)

9-pin jack Signal 25-pin jack

Pin Pin

1 DCD 8

2 RxD 3

3 TxD 2

4DTR20

5GND7

6DSR6

7RTS4

8CTS5

9RI22
