service.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

12-49

Nur für den internen Gebrauch Service

Guided Maintenance

12.4.9.3 The Screen Layout of the Trace Monitor

When you start the Trace Monitor, an application window with the following layout appears:

Figure 12-4 The Screen Layout of the Trace Monitor

Trace window sy-

stem menu

Title bar

Menu bar

Workspace

(open trace win-

dows)

Trace Monitor sy-

stem menu

Minimize

Maximize

Exit

Status bar
