service.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
12-39
Nur für den internen Gebrauch Service
Guided Maintenance
12.4.2.3 Peripheral boards
Viewing peripheral board status
You can use HiPath 3000/5000 Manager E or Assistant T to view the status of all peripheral
boards. Display is limited to the following statuses per board:
● Board not inserted
● Board defective (not loaded)
● Board disabled
● Board enabled (active)
● Board busy (at least one station or line from this board is disconnected, is being called, or
is busy).
For ISDN boards, the status of the reference clock is displayed:
● No reference clock
● Reference clock for clock generator is created.
When viewing the board status using the HiPath 3000/5000 Manager E, all peripheral boards
integrated into the system are presented in a table. The status display is updated every 3 sec-
onds.
With Assistant T, you can only view the status of one board at a time. You can also update the
status display by pressing a key.
You cannot perform additional activities with the HiPath 3000/5000 Manager E and Assistant T
while viewing the status of a board.
Table 12-4 HiPath 3000/5000 Manager E - Example of Status Display of Peripheral
Boards
Slot Board Not
inserted
Defective Blocked Free Res. Clock
source
1STLS2 X X X
2SLU8 X
3SLA4 X X
4 TLA8 X
5
6
7TS2N X X
8 16SLA X
9
10 SLMO24 X
