Siemens Hipath 5000 Service Documentation

sysdat.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
2-35
Nur für den internen Gebrauch System Data
HiPath 3000
2.1.7.4 Peripheral components, HiPath 3500
Subscriber Line Modules
Table 2-18 Subscriber Line Modules for HiPath 3500
Board
Name
Capacity Coun-
try
Type/Description
Ports per board B channels per board Max. number of boards per system ROW USA
8SLAR 8 #
1
1 The maximum number is calculated on the basis of the system-specific capacity limits, See Section 2.3, “System-Specific
Capacity Limits for HiPath 3000, HiPath 5000”.
x x Board for connecting analog stations (a/b, T/R)
HXGR3 2 8 3 x x HG 1500 board for the direct connection of IP workpoint cli-
ents.
IVMS8NR 8 8 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (8 ports).
IVMS8R 8 8 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (8 ports).
IVMP4R 4 4 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (4 ports).
SLAD8R 8 #
1
x x Board for connecting analog stations (a/b, T/R)
SLU8R 8 16 #
1
x x Board for connecting telephones with U
P0/E
interface (TDM)
STLS4R 4 8 #
1
x x Board for ISDN basic rate access.
Configuration of ISDN trunks, tie trunks, and stations (no
feeding) on the same board is possible.
