HiPath 3000/5000 V9, Service documentation
11-3
Nur für den internen Gebrauch HiPath Cordless Office
System Configuration
11.2 System Configuration
The following table indicates the maximum possible system configuration parameters for Hi-
Path Cordless Office. It also shows when
● CMA or CMS is necessary
● analog trunk access is possible.
Table 11-1 HiPath Cordless Office - System Configuration for HiPath 3000 V9
System
Max. no.
Clock modules
Maximum number of base sta-
tions BS with connection via
1xU
P0/E
Simultaneous
calls per BS
Max. no.
MTs
Analog
trunk access
of the system
SLC16N
SLCN
BS3/1
BS3/S
BS3/3
BS4
BS3/1
BS3/S
BS3/3
BS4
HiPath 3350
HiPath 3300
– – CMS – 1 – 1 – 1/2 – 1/2 8 No
––CMA 1 – – 1 1/4––1/4 8 Yes
– – CMA 3 – – 3 1/4 – – 1/4 16 Yes
HiPath 3550
HiPath 3500
––CMS – 1 – 1 –1/2–1/2 8No
––CMA 1 – – 1 1/4––1/4 8 Yes
– – CMA 7 – – 7 1/4 – – 1/4 32 Yes
HiPath 3550 1 – CMS 16 – 16 16 1/4 – 3/12 3/12
64 (with 1
SLC16N)
Yes
HiPath 3800 – 4 CMS 64 – 64 64 1/4 – 3/12 3/12
250 (with 4
SLCN)
1
1 Up to 128 handsets are possible at an SLCN.
Yes
Explanations:
● BS3/1 (S30807-H5482-X): is a base station that supports a maximum of 4 calls.
● BS3/3 (S30807-H5485-X): is a base station that supports a maximum of 12 calls when connected using
three U
P0/E
interfaces.
● BS3/S (X30807-X5482-X100): The BS3/S single-cell base station guarantees the operation of a maximum
of one base station on the U
P0/E
interfaces of the central board. It is not possible to operate additional base
stations.
● BS4 (S30807-U5491-X): is a base station that supports a maximum of 12 calls when connected using three
U
P0/E
interfaces. In the case of a direct connection, it is only permitted to make the connection via one U
P0/
E
interface. The B channels in the base station BS4 require a license (see Chapter 8).
