Page #622 background imageLoading...
Page #622 background image
Installing HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
4-90 HiPath 3000/5000 V9, Service documentation
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.2.3.2 Unpacking the Components
Procedure
4.2.3.3 Not for U.S.: Mounting the Main Distribution Frame (HiPath 3550 only)
Introduction
MDFU is the main distribution frame used (see Figure 4-49).
Installation notes
The MDFU-E main distribution frame should be installed in the direct vicinity of the system
(note length of connection cable) and at eye level. Mount it on the wall according to the instruc-
tions that came with it. The bag attached to the cover contains a drill template. It also contains
the necessary screws and wall anchors for attaching the MDF to the wall.
The MDFU must be grounded. Refer to Section 4.2.3.6 for an explanation of the procedure.
Step Activity
1. Compare the components with the packing slip or customer receipt to make sure
that they are correct and complete.
2. Determine whether any damage has occurred during transport and report it to the
proper departments.
3. Dispose of the packing materials properly.
7
Caution
Only use tools and equipment that are in perfect condition. Do not use equipment
with visible damage.
