A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

9-1

Nur für den internen Gebrauch Expanding and Upgrading HiPath 3000

9 Expanding and Upgrading HiPath 3000

Chapter contents

This chapter covers the following topics:

Topic

HiPath 3000Expanding, page 9-2:

● Replacing Peripheral Boards for HiPath 3800, page 9-2

● Connecting a Printer, page 9-4

● Inserting Powerbox PB3000, page 9-6

● Connecting Special Equipment, page 9-25

Upgrading HiPath 3000, page 9-30

● Hardware Upgrade, page 9-30

● Upgrading from V8 to V9, page 9-32

● Upgrade HiPath 3000 for Signaling & Payload encryption (SPE), page 9-35

Default Chapter3
- Table of Contents3
