Guided Maintenance
Options available?
You can call up the following options using the HiPath 3000/5000 Manager E:
● CMA
● CMS
● LIM
● IMODN
● Announcement and music modules:
– MPPI (Product of BEYERTONE GmbH)
– MUSIC (Product of Sound Player GmbH)
– UAM (only with HiPath 3550, HiPath 3350) or
UAMR (only with HiPath 3500, HiPath 3300)
The availability of one of these announcement and music modules is displayed as
"Option 5". The ALUM4 module cannot be displayed.
12.4.2.2 Power Supplies
Table 12-3 Power Supply Status Displays
Board Status display
HiPath 3800
LUNA2 The LED displays the operating status (on or off).
Powerbox PB3000 The LED displays the operating status (on or off).
HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300
PSUP The LED displays the 5-V output voltage.
UPSC-D, UPSC-DR
● A green LED displays the 5-V output voltage.
● A yellow LED displays the additional power of -48-V output volt-
age provided by an external power supply unit (Powerbox
PB3000).
Power Box PB3000 The LED displays the operating status (on or off).
