boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-51
Nur für den internen Gebrauch Boards for HiPath 3000
Central Board
3.2.10 LIM
Introduction
The LAN Interface Module LIM (S30807-Q6930-X) is an optional plug-in card for all central con-
trol boards of HiPath 3000 with the exception of the CBSAP (HiPath 3800), the CBCC (HiPath
3550, HiPath 3350) from S30810-Q2935-A401 or later, and the CBRC (HiPath 3500, HiPath
3300) from S30810-Q2935-Z401 or later.
The board provides an Ethernet (10BaseT/10 megabit) LAN connector via an 8-pin RJ45 jack.
The LIM module can, for example, be used for the following applications:
For administration using HiPath 3000/5000 Manager E
For the TAPI 120/170 connection via the CSTA interface. Bear in mind, however, that
the number of BHCAs (Busy Hour Call Attempts = number of connection attempts dur-
ing busy traffic hours) is restricted to 400 at a maximum of six CSTA links for the TAPI
120/170 connection. The use of “power dialers” is not approved.
For the output of call data
In V6.0 or later, the system software deactivates an existing LIM module when an HG 1500
board is inserted. You cannot operate the LIM module and a HG 1500 board simultaneously in
a HiPath 3000.
7
Caution
The LAN interface module must not be plugged in or out when the system is ener-
gized. Place the central control board on a flat surface before inserting the LIM sub-
board.
The spacing bolts supplied guarantee the correct insertion of the subboard, so you
should always mount them (see Figure 3-7).
Otherwise you may damage the board.
