optiPoint 500
10.5.3.6 Possible optiPoint Adapter Configurations
Adapter categories
Each U
P0/E
port in the system provides two B channels. This means that you can connect two
telephones, each with a separate phone number, to one U
P0/E
port.
Category 1 optiPoint 500 adapters
The following adapters each require a B channel and, therefore, can only be used once on a
host terminal (host terminal requires the second B channel of the
U
P0/E
port).
● optiPoint analog adapter
● optiPoint ISDN adapter
● optiPoint phone adapter
If one of these adapters is used in the optiPoint 500 advance, only a category 2 adapter can be
operated in the second slot.
Category 2 optiPoint 500 adapters
The following adapters can be used on the host and client telephones. This is also true if a cat-
egory 1 optiPoint 500 adapter is already connected.
● optiPoint acoustic adapter
● optiPoint recorder adapter
Configuration restrictions
Number of usable adapters and key modules
HiPath 3000/5000 shows the maximum number of adapters and key modules that can be con-
nected to Section 10.5.5. The limits also include the client telephones connected over optiPoint
phone adapters and the analog telephones connected over optiPoint analog adapters.
>
The voltage feed test can be used to check whether a local power supply is also nec-
essary for an adapter configuration. To avoid any doubts, the test should always be
implemented when installing large configurations.
