Page #814 background image
Expanding and Upgrading HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
9-30 HiPath 3000/5000 V9, Service documentation
exup.fm
Upgrading HiPath 3000
9.2 Upgrading HiPath 3000
The following information describes the measures that are needed to upgrade the hardware
and software.
9.2.1 Hardware Upgrade
The following hardware requirements apply to HiPath 3000/5000 V5.0 and higher.
Control boards
If the control board necessary for operating HiPath 3000/5000 V5.0 and higher is not available,
a replacement must be performed.
For Deutsche Telekom AG only: The CBCP board S30810-Q2935-B201 must be replaced by
a CBCC board S30810-Q2935-A301.
Multimedia card MMC
For the operation of HiPath 3000/5000 V9, an MMC with minimum 128 MB is required.
>
It is not possible to upgrade HiPath 3550 to HiPath 3500 or HiPath 3350 to HiPath
3300. This would require replacing the complete system.
System Control board necessary for HiPath 3000/5000 V5.0 and higher
HiPath 3800 CBSAP (S30810-Q2314-X and higher)
HiPath 3550
HiPath 3350
CBCC (S30810-Q2935-A401, S30810-Q2935-A301)
HiPath 3500
HiPath 3300
CBRC (S30810-Q2935-Z401, S30810-Q2935-Z301)
>
Note for upgrading from hardware < version 1.2:
If the following subboards are present, they must be replaced: IMODN (replaces the
IMOD), MMC (replaces the FMC), CMA/CMS (replaces the CGM/CGMC).
