3.3.2 DIUN2

Introduction

The DIUN2 (Digital Interface Unit ISDN) provides 2 x 30 B channels (voice channels) for HiPath

3800. These are used

● for the S

trunk connection (via NT).

● for S

networking via S

lines.

Front panel

In HiPath 3000/5000 V5.0 and later, the B channels in the DIUN2 board are subject

to license. Information on licensing can be found in Chapter 8.

Figure 3-32 DIUN2 - Front Panel (S30810-Q2196-X)

Two LEDs indicating the board status:

● LED (green)

● LED (red)

Interface 2

Interface 1

Default Chapter3
