Service Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
12-40 HiPath 3000/5000 V9, Service documentation
service.fm
Guided Maintenance
Locking out and releasing boards and ports
Using the HiPath 3000/5000 Manager E and Assistant T, you can lock out a complete station
or trunk module. The lockout prevents renewed seizure after the current connection has fin-
ished. Release or lock out settings are retained after a reset.
The first SLMO/SLU board can be blocked. This action does not block the first two ports. You
can block specific ports with the “Block selection” option.
Ports of an IVM or HG 1500 board cannot be locked.
When attempting to lock out the last active trunk, you are subsequently notified that remote ser-
vice through the service center is no longer possible.
12.4.3 Recording HiPath 3000 Trunk Status
HiPath 3000 records the current status of each individual trunk in a table. If the status changes,
the new status along with the time stamp is entered. You can use HiPath 3000/5000 Manager
E to view the trunk status, in which case the following information is provided.
Data Contents
Date Date of the event (as stored in system)
Time Time of the event (as stored in system)
Trunk number Number of the trunk
Slot/Port Slot and port number
Status ● Trunk status:
– Inactive
– Incoming call
– Outgoing call
– Trunk-to-trunk connection
– Trunk disabled (using lockout switch or HiPath 3000/5000
Manager E)
– Trunk failure
● Number of the connected station
