boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-53
Nur für den internen Gebrauch Boards for HiPath 3000
Central Board
3.2.11 LIMS
Introduction
The LAN Interface Module for SAPP LIMS (S30807-Q6721-X) is an optional plug-in card for
the CBSAP central control board in HiPath 3800.
The board provides two Ethernet (10BaseT) LAN connectors via two 8-pin RJ45 jacks:
● LAN1 (administration via HiPath 3000/5000 Manager E and CTI functions)
● LAN2 (not assigned)
The LIMS module can, for example, be used for the following applications:
– For administration using HiPath 3000/5000 Manager E
– For the TAPI 120/170 connection via the CSTA interface. Bear in mind, however, that
the number of BHCAs (Busy Hour Call Attempts = number of connection attempts dur-
ing busy traffic hours) is restricted to 400 at a maximum of six CSTA links for the TAPI
120/170 connection. The use of “power dialers” is not approved.
– For the output of call data
In V6.0 or later, the system software deactivates an existing LIMS module when an STMI2
board is inserted. You cannot operate the LIMS module and an STMI2 board simultaneously
in a HiPath 3800.
7
Caution
The LIMS module must not be plugged in or out when the system is energized.
