HiPath 3000/5000 in the LAN Network Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

13-34 HiPath 3000/5000 V9, Service documentation

h3h5_in_the_lan.fm

HG 1500 Board

13.6.9 Virtual Private Network (VPN)

Virtual Private Networks (VPN) connect individual computers and local networks via the Inter-

net to form a closed virtual network. Communication in a VPN is tunneled through the Internet

(encapsulated) and is protected from tapping and access by third parties such as Internet users

and providers that are not a part of the VPN. A VPN enables an intranet to be extended beyond

the LAN, for example to home workstations

or branch offices, without requiring a dedicated line.

Figure 13-4 VPN - Sample Configuration

HiPath 3000

with HG 1500

HiPath 3000

with HG 1500

Teleworker A

VPN tunnel

Switch

LAN B

LAN C
