A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-395

Nur für den internen Gebrauch Boards for HiPath 3000

Options

3.4.15 USB V.24 Adapter

The following adapters have been tested for connecting serial devices to the USB interface on

the service PC:

● Serial USB adapter F5U103 from Belkin Corporation (www.belkin.com)

● Serial USB adapter BF-810 from BAFO Technologies (www.bafo.com)

The delivery includes one USB cable, the adapter and a CD-ROM with drivers.

Notes:

● The drivers provided must be used.

● If a connection cannot be established between the PC and the system, close the Transfer

dialog and then reopen it.
