A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

11-1

Nur für den internen Gebrauch HiPath Cordless Office

11 HiPath Cordless Office

Overview

This chapter contains basic information about the operation of HiPath Cordless Office. For

more detailed information, please refer to the HiPath Cordless Office service manual.

Chapter contents

This chapter covers the following topics:

Topic

Introduction, page 11-2

System Configuration, page 11-3

Technical Data for Base Stations, page 11-4

Power-Related Capacity Limits, page 11-6

Multi-SLC and System-Wide Networking, page 11-9

Planning Notes for Networked HiPath 3000 Systems Featuring Network-Wide Roaming, page

11-11

Default Chapter3
