Siemens Hipath 5000 Service Documentation

sysdat.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
2-31
Nur für den internen Gebrauch System Data
HiPath 3000
2.1.7.3 Peripheral components, HiPath 3350
Subscriber Line Modules
Table 2-14 Subscriber Line Modules for HiPath 3350
Board
Name
Capacity Coun-
try
Type/Description
Ports per board B channels per board Max. number of boards per system ROW USA
4SLA 4 2 x - Board for connecting analog stations (a/b, T/R)
8SLA 8 2 x x Board for connecting analog stations (a/b, T/R)
16SLA 16 2 x - Board for connecting analog stations (a/b, T/R)
HXGS3 2 8 1
(2
1
)
1 The system may be configured with two HG 1500 boards if PDM1 is not used.
x x HG 1500 board for the direct connection of IP workpoint cli-
ents.
IVMP4 4 4 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (4 ports).
IVMP8 8 8 1 x - Board for the integrated voicemail functions in HiPath
Xpressions Compact (8 ports).
IVMS8 8 8 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (8 ports).
IVMS8N 8 8 1 x x Board for the integrated voicemail functions in HiPath
Xpressions Compact (8 ports).
SLAD4 4 2 x x Board for connecting analog stations (a/b, T/R)
SLAD8 8 2 x x Board for connecting analog stations (a/b, T/R)
SLAD16 16 2 x x Board for connecting analog stations (a/b, T/R)
SLU8 8 16 2 x x Board for connecting telephones with U
P0/E
interface (TDM)
STLS2 2 4 2 x - Board for ISDN basic rate access.
Configuration of ISDN trunks, tie trunks, and stations (no
feeding) on the same board is possible.
STLS4 4 8 2 x x
