Nur für den internen Gebrauch Installing HiPath 3000
Installing HiPath 3800
4.1.3.3 Setting up the System Cabinets
Introduction
The cabinets are not supplied with pre-installed boards. For information on board installation,
please see Section 4.1.5, “Installing Boards (Configuration Notes)”.
If it has been agreed to provide connector panels for connecting peripherals, these are included
in the delivery. For information on the installation procedure, please see Section 4.1.5.4,
“Mounting Connector Panels (if required)”.
The front plastic cover (for board servicing) and the rear plastic cover (for cable servicing) are
not attached to the system cabinets. Both covers are supplied in separate packages.
4.1.3.3.1 Overview
System configurations
The following setup options are possible for system cabinets:
● Single cabinet
● Two cabinets (stacked)
● Two cabinets (side by side)
7
Danger
Be sure to connect the main protective earthing terminal on all system cabinets to
the grounding point of the electrical building installation before starting the system
and before connecting up the peripherals (for example, potential equalization bus).
The system may only be started (connected to the power supply) if all system cabi-
nets are sealed at the rear with the connection and filler panels provided.
