Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-210 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
3.3.20 SLMO8 (not for U.S.), SLMO24
Introduction
The SLMO8 and SLMO24 boards (Subscriber Line Module Cost Optimized U
P0/E
) provide 8
and 24 U
P0/E
interfaces for optiPoint and OpenStage telephones on HiPath 3550.
Switches and LEDs
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
Figure 3-64 SLMO8 (not for U.S.), SLMO24 (S30810-Q2901-X100, S30810-Q2901-X)
H1 (green)
H2 (red)
LEDs
Lockout switch S1
(position = free,
factory default)
