Workpoint Clients Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
10-90 HiPath 3000/5000 V9, Service documentation
wclient.fm
optiPoint 500
10.5.1.7 Connection
Procedure: Connecting an optiPoint 500 Telephone
The first time the telephone is switched on,
all LEDs light up briefly
all LEDs on the add-on devices (AODs), if connected, light up briefly (AOD LEDs do not
necessarily flash at the same time as the LEDs on the telephone)
all pixels on the display activate briefly.
Step Activity
1. Locate a free interface on the main distribution frame or internal distributor for
connecting the telephone.
2. Connect the cable from the main distribution frame or internal distributor to the
wall outlet.
>
The maximum range for a standalone or host telephone without additional local
power supply is approximately 1000 m (3280 feet) (for J-Y (ST) 2x2x0.6, 0.6 mm).
Perform the terminal test in Section 12.4.11 to determine whether a local power sup-
ply is needed for additional power (for example, in host-client configurations or for
larger ranges).
3. Label the keys. You have the following options:
by hand (in writing); label sheets come with each telephone.
using a PC:
with the “Key Labeling Tool” (requires MS Word
©
) which is contained on
the “Electronic Operating Instructions” CD.
with the “Key Labeling Tool”, which can be called via:
https://siemens-enterprise.com/us/support.aspx
4. Prepare the telephone for connection:
Connect the handset cord to the telephone (marked with symbol) and to the
handset.
Do you plan to connect an add-on device? Refer to Section 10.5.2 on
page 10-93 for more information.
Do you plan to connect an optiPoint adapter? Refer to Section 10.5.3 on
page 10-95 for more information.
5. Connect the line cord (marked on the telephone by a symbol).
optiPoint 500 telephones are shipped with a 6 m (20 ft.) line cord and an MW6
(RJ11) plug for connection to a modular telephone jack.
