Siemens Hipath 5000 Service Documentation

System Data Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
2-38 HiPath 3000/5000 V9, Service documentation
sysdat.fm
HiPath 3000
2.1.7.5 Peripheral components, HiPath 3300
Subscriber Line Modules
STRBR Sensors 4 x x Control relay module; provides 4 relays and 4 sensors
for controlling external devices or detecting external
control events.
Relay 4
Table 2-22 Subscriber Line Modules for HiPath 3300
Board
Name
Capacity Coun-
try
Type/Description
Ports per board B channels per board Max. number of boards per system ROW USA
8SLAR 8 2 x x Board for connecting analog stations (a/b, T/R)
HXGR3 2 8 1
(2
1
)
x x HG 1500 board for the direct connection of IP workpoint cli-
ents.
IVMP4R 4 4 1 x x These boards are for the integrated voicemail functions in
HiPath Xpressions Compact (4 ports).
IVMP8R 8 8 1 x x These boards are for the integrated voicemail functions in
HiPath Xpressions Compact (8 ports).
IVMS8NR 8 8 1 x x These boards are for the integrated voicemail functions in
HiPath Xpressions Compact (8 ports).
IVMS8R 8 8 1 x x These boards are for the integrated voicemail functions of
HiPath Xpressions Compact.
SLAD8R 8 2 x x Board for connecting analog stations (a/b, T/R)
SLU8R 8 16 2 x x Board for connecting telephones with U
P0/E
interface (TDM)
Table 2-21 Optional Boards for HiPath 3500
Board
Name
Capacity Coun-
try
Type/Description
ROW USA
