Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-82 HiPath 3000/5000 V9, Service documentation

wclient.fm

optiPoint 500

10.5.1 optiPoint 500 Telephones

10.5.1.1 optiPoint 500 entry

Main features

● 8 function keys with LEDs (can be modified with HiPath 3000/5000 Manager E; for infor-

mation on key programming, see Section 10.6)

● Open listening

● 2 volume adjustment keys (plus/minus) and pitch

● Suitable for wall mounting

● No modularity (no connection option for adapters or key modules), no display

Standard key assignment (default) for optiPoint 500 entry

Refer to Section 10.5.1.6 for connection requirements.

Figure 10-36 optiPoint 500 entry - Standard Key Assignment (Default)

Consultation hold

Redial

Message

Callback

Speed dialing

Microphone on/off

Loudspeaker

Disconnect
