h3h5_in_the_lan.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
13-63
Nur für den internen Gebrauch HiPath 3000/5000 in the LAN Network
Applications over IP
13.9.1.2 TCP Client in HiPath 3000/5000
When call data records accumulate, the TCP client (HiPath 3000/5000) sets up a TCP/IP con-
nection to an external TCP server (external application) and transmits the data. The connection
remains active continuously so that the system can send any further accumulated data, trans-
mitting each data record separately.
13.9.1.3 TFTP Server in HiPath 3000/5000
The external application (TFTP client) requests output of the call data records. To do this, the
application must set up a connection and indicate the service (GET gez.txt), after which it re-
ceives all accumulated call data records. It releases the connection after the transfer.
The application’s request for call data can be controlled automatically or using an SNMP trap
(see Section 13.10.2). HiPath 3000/5000 sends the SNMP trap (“data available”) to the external
application, generating the trap using a programmable threshold value determining the call
data buffer capacity (0 to 80 percent of the call data buffer full).
TCP client
HiPath 3000/5000
External appli-
cation
TCP protocol
TCP server
TFTP Ser-
ver
HiPath 3000/5000
External appli-
cation
TFTP protocol
TFTP cli-
ent
TFTP cli-
ent
