Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-14 HiPath 3000/5000 V9, Service documentation

wclient.fm

OpenStage Product Family

10.1.2.5 OpenStage 40

Product image

Versions

The following telephones are available for the CorNet IP (HFA) connection variant:

● OpenStage 40

● OpenStage 40 G (gigabit variant)

Main features

Figure 10-5 OpenStage 40

Feature Connection variant

CorNet-IP (HFA) TDM

General fea-

tures

Tilt LCD graphics display with background lighting, 40 x 6 character resolu-

tion, monochrome

multi-functional 5-way navigator
