Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-340 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
3.3.45 TST1 (for U.S. only)
Introduction
The digital T1/PRI trunk module (TST1) connects the communications server to primary rate
interface (PRI) ISDN via a T1 interface.
There are two versions of this board:
S30810-Q2919-X - for use in the HiPath 3550 (wall housing)
S30810-K2919-Z - for use in the HiPath 3500 (19-inch housing)
The board can also be used for the following layer-1 operating modes:
Super Frame SF
Extended Super Frame ESF
Board usage is subject to the following restrictions:
Only one TST1 board allowed (primary multiplex access)
For slot 7 or 9 only
Rather than connecting to a main distribution frame (MDF), the TST1 connects to a channel
service unit (CSU). The CSU provides the required primary protection.
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
