System Data Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
2-78 HiPath 3000/5000 V9, Service documentation
sysdat.fm
Dynamic Configuration Rules
Calculation
Conclusion
The calculated required performance of 332 points is less than the total performance of 980
points that the STMI2 board can provide. The configuration is feasible.
Table 2-58 Resource requirement for ISDN and ITSP connection for HiPath 3800
Function Formula Points
Signaling without H.235 security (inde-
pendent of the setting “Enhanced B
Channels”)
100 x IP telephones/clients,
8 calls per hour
100 x 0.68 68
Payload (setting “Enhanced B Chan-
nels” activated)
Gateway channel via LAN 1 without en-
cryption
24 x G.711
(Receive: 20 ms/sent: 20 ms)
24 x 11 264
Total 332
