Product Specific Attributes
HiPath 5000 V7
Issue: 18
th
April 2007 Page - 15 -
Siemens Enterprise Communications GmbH & Co KG
2.2 Administration and Diagnosis
The following services are needed for administration and diagnosis in addition to those listed in
chapter Voice Traffic and Signaling
OAM (H5k) Adminstration and Maintenance HiPath 5000
ADM (H2/3/5k) Interface to DBFS server
ADM
API
--- TCP 7000
1 -
65535
Def: ADM
Adm: Default can be modified
within this range
HTTP client (HG1500) used for multi
gateway administratrion feature
(MGAF)
client HTTP --- TCP
1024 -
65535
Def: Ephemeral Ports (IANA)
HTTP Server (HG1500) HTTP
Server for WBM access
server HTTP --- TCP 8085 Def: HTTP optiPoints, HG1500
HTTPS client used for multi gateway
administration feature (MGAF)
client
HTTP
S
---
TCP -
SSL
1024 -
65535
Def: Ephemeral Ports (IANA)
HTTPS Server (HG1500) Secure
Web Server
server
HTTP
S
---
TCP -
SSL
443 Def: HTTPS
LDAP Client LDAP client used for
centraliced directory service
client LDAP ---
TCP_UD
P
1024 -
65535
Def: Ephemeral Ports (IANA)
SNMP (SET/GET) (H2/3/5k/HG1500)
SNMP Set/Get
server SNMP --- UDP 161 Def: SNMP (Set/Get)
SNMP (Traps) (H2/3/5/HG1500)
SNMP Erromessages
client SNMP --- UDP
1024 -
65535
Def: Ephemeral Ports (IANA)
SNMP (Traps) (HG1500) Receiving
of SNMP-Traps
server SNMP --- UDP 162 Def: SNMP (Traps)
SNTP Client (H2/3/5k/BizIP) Simple
Network Time Protocol
client SNTP --- UDP
1024 -
65535
Def: Ephemeral Ports (IANA)
TFTP Client (H2/3/5k) APS-Transfer/
KDS-Sicherung mit TFTP
client TFTP --- UDP
1024 -
65535
Def: Ephemeral Ports (IANA)
TFTP Server (H2/3/5k,BizIP) TFTP
Server for CDR
server TFTP --- UDP 69 Def: TFTP
SW_Manager (H5k) HiPath Software Manager
SW-Man Secured Web Access
from a Client Browser HTTPS
Interface of SW-Manager
server HTTPS --- TCP 8443 0 - 65535
Def: HTTPS port of SW-
Manager, DB Feature Server
Adm: Default can be modified
within this range via server.xml
file in Tomcat's "conf" directory
SW-Man Tomcat Shutdown Used
to shutdown Tomcat
server
*proprietar
y*
--- UDP 8279 0 - 65535
Def: Shutdown port of SW-
Manager
Adm: Default can be modified
within this range via server.xml
file in Tomcat's "conf" directory
SW-Man Web Access from a Client
Browser HTTP Interface of SW-
Manager
server HTTP --- TCP 8280 0 - 65535
Def: HTTP port of SW-
Manager
Adm: Default can be modified
within this range via server.xml
file in Tomcat's "conf" directory
X-Trace (H2/3/5k) Access for X-Tracer
Online Trace (H2/3/5k) Online
Trace Port (X-Tracer)
server XTP --- TCP 21965 Def: X-Tracer
X-Trace (HG1500) Access for X-Tracer
Online Trace (HG1500) Acces to X-
Trace
server XTP TCP
204
8
Def: XTrace
