Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-32 HiPath 3000/5000 V9, Service documentation

boards.fm

Central Board

V.24 interface assignment

LAN connector assignment

CBRC S30810-Q2935-Z301: The Ethernet LAN interface is provided by the optional LIM sub-

board.

Table 3-13 CBRC - V.24 Interface Assignment (SUB-D Plug)

X18, Pin Signal Description

1 – Not used

2 RxD A Receive data, channel A

3 TxD A Transmit data, channel A

4 – Not used

5 0 V Ground

6 – Not used

7 RTS A Request to send, channel A

8 CTS A Clear to send, channel A

9 – Not used

Table 3-14 CBRC - LAN Connector Assignment (RJ45 Jack) via LIM

Pin Signal Description

1 Tx + Transmit +

2 Tx – Transmit –

3Rx+Receive+

4 – Not used

5 – Not used

6Rx–Receive–

7 – Not used

8 – Not used
