Central Board
Default numbering plan when using CBRC in HiPath 3300
Table 3-16 Default numbering plan when using CBRC in HiPath 3300
Station Int. call no. DID no. Port
U
P0/E
host
(master)
11 11 U
P0/E
1
12 12 U
P0/E
2
13 13 U
P0/E
3
14 14 U
P0/E
4
15 15 U
P0/E
5
16 16 U
P0/E
6
17 17 U
P0/E
7
18 18 U
P0/E
8
U
P0/E
client
(slave)
51 51 U
P0/E
1
52 52 U
P0/E
2
53 53 U
P0/E
3
54 54 U
P0/E
4
55 55 U
P0/E
5
56 56 U
P0/E
6
57 57 U
P0/E
7
58 58 U
P0/E
8
T/R 19 19 T/R 1
20 20 T/R 2
21 21 T/R 3
22 22 T/R 3
EVM 23 23 EVM-1
24 24 EVM-2
Line Code Port
S
0
CO PP
801 S
0
1-1
802 S
0
1-2
803 S
0
2-1
804 S
0
2-2
