Siemens Hipath 5000 Service Documentation

Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-108 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
LED statuses and their meanings
LED
yellow
LED
green
Meaning Action
During Startup and Initialization
Off Off 1 Boot procedure (lasts approx. 60 s)
On On 2 LED test (lasts approx. 10 s)
On Off 3 Lockout switch state signaling by
yellow LED (lasts approx. 5 s):
● blocked = On
● free = Off
Possibly check if board was de-
activated using HiPath 3000/
5000 Manager E or lockout
switch.
Off
Flashing
(500/
500 ms)
Off 4 Hard disk test, application startup
(depending on hard disk status,
lasts approx. 2 - 9 minutes)
Off On 5a Standby mode after successful boot
On Off 5b Board locked or board error oc-
curred
Check whether board was deac-
tivated using HiPath 3000/5000
Manager E or lockout switch.
Change board if faulty.
During Operation
Off On Idle (no call)
Flashing
(500/
500 ms)
Off At least one active port (call)
Flashing
(500/
500 ms)
Flashing
(500/
500 ms)
Lockout switch activated during a call
On Off Board locked or board error occurred Check whether board was deac-
tivated using HiPath 3000/5000
Manager E or lockout switch.
Change board if faulty.
Flashing
(100/
100 ms)
Off Upgrade process active
Table 3-45 IVMP4, IVMP4R - LED Statuses
