boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-117

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Front view of IVMS8R

Figure 3-43 IVMS8R - Front View (S30122-K7379-Z)

X3 = LAN connector, 8-pin RJ45

jack

LED (yellow)

LED (green)

Lockout switch
