boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-319

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Front panel

Figure 3-110 TMDID2 (for selected countries only) - LEDs on the Front Panel

To ensure sufficient shielding, provide the board with a shielding panel. For informa-

tion on mounting the shielding panel, see Section 4.1.5.3.

Two LEDs indicating the board status:

● LED (red)

● LED (green)
